Discription and Specification
Standard Bucket: Apply to light operation task, such as digging and loading hard
soil or stones nixed with the soft soil.
Heavy Duty Bucket: Suitable for digging hard soil, soil mixed with soft stone,
loading gravel, broken stone and so on
Rock Bucket: Suitable for digging earth with hard rock, sub-hard stone and
weathered stone, it also can do heavy work, such as digging and
loading solid rock, blasted ore
Skeleton Bucket: Apply to clean the watercourse. It can be used for underwater
work.
Quick Change Bucket:Apply to the construction site which should be worked flexible.
| Type | Material, Configuration,Capability | Application |
Standard | Material:Q345B,standard plate thickness, domestic material high quality tooth
plate. | For digging normally clay, loose soil, sand and loading gravel
light working environment. |
Enhanced | Material:Q345B, plate thickening, domestic material high quality tooth
plate,extend the use of time. | For digging hard soil or loading rubble , gravel with softer rubble
normally light working environment. |
C level Rock | Adapter plate and side plate are made of homemade material Nm360,
domestic material high quality tooth plate, so that it can resist
grinding and bending. | For digging hard soil with tough rubble or loading rubble and
gravel normally light working environment. |
A/B level Rock | Adapter plate and side plate are made of import material HARDOX,
rock tooth plate, consolidated plate on the bottom and side plate,
so that it can resist grinding and bending efficiently. | For loading the tough rock and the mineral after explosion. |
Product Instruction
Parameter
| (Chemical Composition and Machinery Capability) |
Item
Type | Code | Main chemical Composition | Hardness
(HB) | Extension
δ(%) | Drag and Extension intensity(N/m) | Bend intensity(N/m) |
| C | Si | Mn | P | S |
| Mn Board | Q345B | 0.18 | 0.55 | 1.4 | 0.03 | 0.03 | 163-187 | 21 | 470-660 | 345 |
Homemade Regrinding Board | NM360 | 0.20 | 0.3 | 1.3 | 0.02 | 0.006 | 360 | 16 | 1200 | 1020 |
High Intensity Regrinding Board | HARDOX-500 | 0.20 | 0.7 | 1.7 | 0.025 | 0.01 | 470-500 | 8 | 1550 | 130 |
Advantages of our products
1. We can make or design buckets as your request. According to
different operating conditions and customer needs, various kinds of
buckets are designed reasonably from shapes, materials, and stress
features, etc
2. Apart from the Standard bucket, Rocky bucket and Heavy duty
bucket, SF also offering special purpose bucket , such as tilting
bucket, hydraulic thumb, skeleton bucket ,cleaning bucket, grab
bucket, shovel bucket, loader bucket.
OUR SERVICE
1. We provide high quality excavator attachments.
2. We choose the best material for our bucket and own experienced
skills.
3. We can design and make buckets according to our customer
request.
4. We can also support the shipment for our customer.
